This TWF-2524-XL hydraulic cylinder is specifically designed to match the dimensions of the Prince SAE-62524 and Bailey 212255 models. It features a wearband on both the piston and rod gland for added durability. The cylinder has a bore size of 2.5 inches, a rod size of 1.375 inches, and a stroke length of 24 inches. The overall pin to pin length in its retracted state is 32 inches and it has SAE -8 ports. The BE crosstube is 3.25 inches wide and has a pin hole of .765 inches, while the RE crosstube is 2.25 inches wide with the same pin hole size.

TWF-2524-XL 2.5x24x1.37 Hydraulic Cylinder

• 2.5" bore

• 1.375" rod

• 24" stroke

• 32" overall pin to pin length retracted

• SAE -8 ports

• BE crosstube is 3.25" wide with .765" pin hole

• RE crosstube is 2.25" wide with .765" pin hole
